Havasu

Name: Havasu
SKU: HAV150-A150
Availability: InStock

The Havasu is a premium high-power floodlight, it has operational life time of over 6 years. With the IP66 rating, wattage switching, range of beam angle options, and high efficiency of 150lm/W, this floodlight can provide a tailored lighting solutions for a long time to come.

Product Code: HAV150-A150

Old Product Code: KFLD80-150Q666-A150

Data Sheet LDT File

Installation Area

Dimensions

Wattage

Built-in Option

Lumens

CCT

Input Voltage Supply

Beam Angle

Ambient Temperature Range

IK Rating

Colour / Finish

L80B10 Lifetime

L70B50 Lifetime

IP Rating

Power Factor

Protection Rating

LS CRI

SDCM

Default Setting

Maximum Current Draw

Efficiency (lm/W)

Energy Class

Clear

KEY FEATURES

Switchable wattage
High Power, from 80W to 150W
Multiple options for optics including asymmetric options
Flicker free

GENERAL SPECIFICATIONS

Voltage:120-277Vac 50/60Hz

Ambient Temp:-30°C to 50°C

IK Rating:IK09

Installation Area:External

L80B10 Lifetime:252,000 h

L70B50 Lifetime:404,000 h

IP Rating:IP65

Power Factor:0.95

Protection Rating:Class I

LS CRI:70

SDCM:<6

TECHNICAL SUMMARY

Default Setting:150W, 240W

Dimensions:392x422x57, 439x483x67

Max Input Current:1,098 mA, 686 mA

CCT:5,000K

Efficiency (lm/W):170 lm/W, 190 lm/W

Lumen:25,500 lm, 40,800 lm

Beam Angle:60°x60°, 90°x90°, Asymmetric 50°(90°x50°), Type-IV

Energy Class:C
