Kurve II

Name: Kurve II
SKU: KUR34-SCT
Availability: InStock

The Kurve luminaire is an easy-to-install retrofit for standard ceiling tile fittings. The Kurve has switchable CCT and power options, is suitable for standard exposed ďTĒ ceiling systems and ideal for commercial and retail premises, offering aesthetically pleasing curved zinc coated steel finish and acrylic diffuser.

Product Code: KUR34-SCT

Old Product Code: KMRC4030L2A/SCT

Data Sheet LDT File

Installation Area

Dimensions

Driver Maximum Power

Settable CCT

Lumens

Driver Output Current

Built-in Option

Wattage

CCT

Input Voltage Supply

Driver Input Voltage

Colour / Finish

Ambient Temperature Range

Mounting Option

IK Rating

L80B10 Lifetime

L70B50 Lifetime

IP Rating

Power Factor

Protection Rating

Driver Protection Rating

LS CRI

SDCM

Default Setting

Driver Dimensions

Maximum Current Draw

Rated Power

Efficiency (lm/W)

Emergency Luminous Flux

Driver Output Voltage

Energy Class

Clear

KEY FEATURES

Stylish & elegant aesthetic appearance
Flicker free
Ultra-low glare
Optional DALI, 1-10V (0-10V) driver
Colour temperature switchable 3000K/4000K/5000K

GENERAL SPECIFICATIONS

Voltage:220-240Vac 50/60Hz

Driver Voltage:220-240Vac 50/60Hz

Ambient Temp:-20°C to 50°C

IK Rating:IK04

Installation Area:Internal

L80B10 Lifetime:54,000 h

L70B50 Lifetime:54,000 h

IP Rating:IP20

Power Factor:>0.94

Protection Rating:Class III

Driver Protection Rating:Class II

LS CRI:≥82

SDCM:<5

TECHNICAL SUMMARY

Default Setting:4000K

Dimensions:595x595x110

Driver Dimensions:118x42x28

Max Input Current:156 mA

Rated Power (W):34 W

Driver Max. power:36 W

Settable CCT:3000k, 4000k, 5000k

CCT:3000K, 4000K, 5000K

Efficiency (lm/W):88 lm/W

Emergency Luminous Flux (lm):380 lm

Lumen:3,000 lm

Driver Output Current:900

Driver Output Voltage:30-40

Energy Class:F
