Arno Retro LED batten with base 18W/32W 4ft CCT/W switch
Product
Code: ARNT4F32-SCT
- Sheet metal base box that retrofits the traditional T8 battens
- 20mm conduit entry and BESA box fitting points
- Option of base with emergency module
- High efficiency of 120lm/W
- Switchable CCT (3000K/4000K/6000K)
- 2 switchable wattage
- Easy installation with surface mounting clips.
- Plug-in motion sensor
- Flicker free
Product Description
The Kosnic Arno Retro-fit integrated Battens utilise high performance LEDs to offer outstanding lumen efficiency within a very economic package. The battens are a low-profile design suitable for a wide range of general lighting applications from commercial premises to warehouses, factories and garages.
Product Description
The Kosnic Arno Retro-fit integrated Battens utilise high performance LEDs to offer outstanding lumen efficiency within a very economic package. The battens are a low-profile design suitable for a wide range of general lighting applications from commercial premises to warehouses, factories and garages.
General Specifications
Voltage
220-240Vac 50/60Hz
Ambient Temp (°C)
-20°C to 50°C
IK Rating
IK08
Install Area
Internal
Nominal Life
50,000
IP Rating
IP20
Power Factor
>0.94
Class
D
CRI
≥82
Recommended/alternatives
No alternativesDownloadables
Technical Summary
-
Default Setting
4000K at 18W
-
Dimensions (mm)
1224x71x79
-
Max input current
3.8A/800µs
-
L80B10
54,000
-
Rated Power (W)
18
-
Settable Wattage
18W, 32W
-
Settable CCT
3000k, 4000k, 6000k
-
Efficiency (lm/W)
144
-
Emergency Luminous Flux (lm)
300
-
Dimmable
N
