T8 CCT

Name: T8 CCT
SKU: T8CCT09
Availability: InStock

The T8 CCT is a highly energy efficient glass T8 tube that can help you save energy by up to 65%. And with it long life you can keep making savings for years to come. Plus, this version can completely adapt to your needs with its switchable wattage and CCT capabilities.

Product Code: T8CCT09

Data Sheet

Dimensions

Wattage

Settable CCT

Lumens

CCT

Beam Angle

Input Voltage Supply

Cap

Ambient Temperature Range

Colour / Finish

L70B50 Lifetime

IP Rating

Power Factor

Protection Rating

LS CRI

SDCM

Surge Capacity

Default Setting

Maximum Current Draw

Energy Class

Clear

KEY FEATURES

High efficiency up to 150lm/W
Switchable wattage and CCT (3000/4000/6500K)
Save energy by up to 65%
Flicker free

GENERAL SPECIFICATIONS

Voltage:220-240Vac 50/60Hz

Ambient Temp:-20°C to 50°C

L70B50 Lifetime:25,000 h

IP Rating:IP20

Power Factor:0.5

Protection Rating:Class II

LS CRI:82

SDCM:<6

Surge Capacity:1000V

TECHNICAL SUMMARY

Default Setting:17.5W at 4000K, 22W at 4000K, 24W at 4000K, 9W at 4000K

Dimensions:1214x∅28, 1514x∅28, 1778x∅28, 604x∅28

Max Input Current:130 mA, 160 mA, 185 mA, 73 mA

Settable CCT:3000k, 4000k, 6500k

CCT:3000K, 4000K, 6500K

Lumen:1,250 lm, 2,450 lm, 3,100 lm, 3,350 lm

Beam Angle:180

Energy Class:D
