UEM Pro

Name: UEM Pro
SKU: UEM04
Availability: InStock

The Universal Emergency Module (UEM) with available Automatic Self-Test (AST) version is suitable for class III luminaires with integrated LEDs and separate LED drivers. Provides an operation time of three hours. The UEM can be installed within a luminaire or within the ceiling void.

Product Code: UEM04

Data Sheet

UEM/EME Input Voltage

Installation Area

Dimensions

UEM/EME Ambient Temp Range

Colour / Finish

Emergency Option

IP Rating

Mounting Option

Protection Rating

UEM/EME Protection

UEM/EME Dimensions

Output Current

Output Voltage

Clear

KEY FEATURES

Standard/Self-test
Built-in loop-in loop-out terminals for 2 x 3-core cables
Built-in cable clamp, push to release
Loop-in and loop-out push-wire terminals
Built-in self-test function according to BS-EN-62034-2012
Designed for use with all LED luminaires (class III) with external driver
Easy Plug & Play installation
For maintained or non-maintained emergency lighting systems
Internal Li-ion battery with improved lifespan
Easy battery replacement

GENERAL SPECIFICATIONS

Voltage:220-240Vac 50/60Hz

Ambient Temp:0°C to 45°C

Installation Area:Internal

IP Rating:IP20

Protection Rating:Class II

TECHNICAL SUMMARY

Dimensions:211x91x32

Output Current:35-85, 50-135

Output Voltage:24-54, 24-54Vdc
